www.irf.com
Preliminary Data Sheet
12
International
Rectifier
IRVR101
Excitation Limitation (current or duty cycle) Signal to the Regulator (D)
2.0 - 7.75 amps, 5 bits (3:0 – 3:4), 32 values (bit select option: 3:5 = 0).
Limitation of the excitation current to the rotor. Default; max excitation current (100% duty cycle).
PWM Field Current
Maximum
Excitation
(5)43210
7.75
(0)11111
7.5
(0)11110
7.25
(0)11101
7.0
(0)11100
6.75
(0)11011
6.5
(0)11010
6.25
(0)11001
6.0
(0)11000
5.75
(0)10111
5.5
(0)10110
5.25
(0)10101
5.0
(0)10100
4.75
(0)10011
4.5
(0)10010
4.25
(0)10001
0-100%, 5 bits (3:0 – 3:4), 32 values (bit select option: 3:5 = 1).
Limitation of the excitation duty cycle to the rotor. Default 100%
PWM Field Duty
Cycle Maximum
Excitation
(5)43210
100%
(1)11111
93.75
(1)11110
90.625
(1)11101
87.5
(1)11100
84.375
(1)11011
81.25
(1)11010
78.125
(1)11001
75
(1)11000
71.875
(1)10111
68.75
(1)10110
65.625
(1)10101
62.5
(1)10100
59.375
(1)10011
56.25
(1)10010
53.125
(1)10001
Byte 3
Bit:
4.0
3.75
3.5
3.25
3.0
2.75
2.5
2.25
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
Full field
(0)10000
(0)01111
(0)01110
(0)01101
(0)01100
(0)01011
(0)01010
(0)01001
(0)01000
(0)00111
(0)00110
(0)00101
(0)00100
(0)00011
(0)00010
(0)00001
(0)00000
Byte 3
Bit:
50
(1)10000
(1)01111
(1)01110
(1)01101
(1)01100
(1)01011
(1)01010
(1)01001
(1)01000
(1)00111
(1)00110
(1)00101
(1)00100
(1)00011
(1)00010
(1)00001
(1)00000
46.875
43.75
40.625
37.5
34.375
31.25
28.125
25
21.875
18.75
15.625
12.5
9.375
6.25
3.125
0
