| 型號： | MCP6566UT-E/OT |
| 廠商： | Microchip Technology |
| 文件頁數： | 16/30頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC COMPARATOR O-D 1.8V SOT23-5 |
| 產品培訓模塊： | MCP656x |
| 標準包裝： | 1 |
| 類型： | 通用 |
| 元件數： | 1 |
| 輸出類型： | CMOS，開路漏極 |
| 電壓 - 電源，單路/雙路(±)： | 1.8 V ~ 5.5 V |
| 電壓 - 輸入偏移（最小值）： | 10mV @ 5.5V |
| 電流 - 輸入偏壓（最小值）： | 1pA @ 5.5V |
| 電流 - 輸出（標準）： | 50mA |
| 電流 - 靜態（最大值）： | 130µA |
| CMRR, PSRR（標準）： | 66dB CMRR，70dB PSRR |
| 傳輸延遲（最大）： | 80ns |
| 磁滯： | 5mV |
| 工作溫度： | -40°C ~ 125°C |
| 封裝/外殼： | SC-74A，SOT-753 |
| 安裝類型： | 表面貼裝 |
| 包裝： | 標準包裝 |
| 產品目錄頁面： | 681 (CN2011-ZH PDF) |
| 其它名稱： | MCP6566UT-E/OTDKR |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁當前第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁
DS580F6
31
CS8406
12.APPLICATIONS
12.1 Reset, Power Down and Start-Up
When RST is low, the CS8406 enters a low power mode and all internal states are reset, including the con-
trol port and registers, and the outputs are disabled. In Software Mode when RST is high, the control port
becomes operational and the desired settings should be loaded into the control registers. Writing a 1 to the
RUN bit will then cause the part to leave the low power state and begin operation. In Hardware Mode when
RST is high, the part will automatically leave the low power state and begin operation.
12.2 ID Code and Revision Code
The CS8406 has a register that contains a four-bit code to indicate that the addressed device is a CS8406.
This is useful when other CS84XX family members are resident in the same or similar systems, allowing
common software modules.
The CS8406 four-bit revision level code is also available. This allows the software driver for the CS8406 to
identify which revision of the device is in a particular system, and modify its behavior accordingly. To allow
for future revisions, it is strongly recommended that the revision code is read into a variable area within the
microcontroller, and used wherever appropriate as revision details become known.
12.3 Power Supply, Grounding, and PCB layout
The CS8406 operates from a VD = +3.3 V or +5.0 V and VL = +3.3 V or +5.0 V supply. These supplied may
be set independently. Follow normal supply decoupling practices, see Figures 5 and 6. The VD and VL sup-
plies should be decoupled with a 0.1 F capacitor to GND to minimize AES3 transmitter induced transients.
Extensive use of power and ground planes, ground plane fill in unused areasand surface mount decoupling
capacitors are recommended. Decoupling capacitors should be mounted on the same side of the board as
the CS8406 to minimize inductance effects, and all decoupling capacitors should be as close to the CS8406
as possible.
12.4 Synchronization of Multiple CS8406s
The AES3 transmitters of multiple CS8406s can be synchronizedif all devices sharethe same master clock,
TCBL, and RST signals. The TCBL pin is used to synchronize multiple CS8406 AES3 transmitters at the
channel status block boundaries. One CS8406 must have its TCBL set to master; the others must be set to
slave TCBL. Alternatively, TCBL can be derived from external logic, whereby all CS8406 devices should be
set to slave TCBL.
