MCS7840
USB-2.0 to Four Serial Ports
Rev.
1.2
Page 19
Divisor Latch Registers (DLL & DLM):
The Divisor Latch Registers are used to program the BAUD Rate divisor.
This is a value between 1 and 65535 by which the input clock is divided in order to generate serial BAUD
rates.
After the hardware reset, the BAUD Rate used by the transmitter & receiver is given by:
BAUD Rate = Input Clock / (16 * Divisor)
where divisor is given by (256 * DLM) + DLL.
More
fl
exible BAUD rate generation options are also available.
Register:
Description:
Offset:
Permissions:
Access Condition:
Default Value:
DLL
Divisor Latch (Least Signi
fi
cant Byte)
0
Read/Write
LCR[7] = 1
0x01
Bit[7]
Bit[6]
Bit[5]
Least Signi
fi
cant Byte of divisor latch
Bit[4]
Bit[3]
Bit[2]
Bit[1]
Bit[0]
Register:
Description:
Offset:
Permissions:
Access Condition:
Default Value:
DLM
Divisor Latch (Most Signi
fi
cant Byte)
1
Read/Write
LCR[7] = 1
0x00
Bit[7]
Bit[6]
Bit[5]
Bit[4]
Bit[3]
Bit[2]
Bit[1]
Bit[0]
Most Signi
fi
cant Byte of divisor latch
