ML4841
REV. 1.0 10/12/2000
3
ABSOLUTE MAXIMUM RATINGS
Absolute maximum ratings are those values beyond which
the device could be permanently damaged. Absolute
maximum ratings are stress ratings only and functional
device operation is not implied.
V
CC
Shunt Regulator Current ..................................55mA
I
SENSE
Voltage ................................................... -3V to 5V
Voltage on Any Other Pin ..... GND - 0.3V to V
CCZ
+ 0.3V
I
REF............................................................................................
20mA
I
AC
Input Current ....................................................10mA
Peak PFC OUT Current, Source or Sink.................500mA
Peak PWM OUT Current, Source or Sink ..............500mA
PFC OUT, PWM OUT Energy Per Cycle.................. 1.5mJ
Junction Temperature ............................................. 150°C
Storage Temperature Range...................... –65°C to 150°C
Lead Temperature (Soldering, 10 sec) ..................... 260°C
Thermal Resistance (
θ
JA
)
Plastic DIP .......................................................80°C/W
Plastic SOIC ................................................... 105°C/W
OPERATING CONDITIONS
Temperature Range
ML4841CX.................................................0°C to 70°C
ML4841IX ...............................................-40°C to 85°C
ELECTRICAL CHARACTERISTICS
Unless otherwise specified, I
CC
= 25mA, R
T
= R
RAMP1
= 23k
, C
T
C
RAMP1
= 400pF, T
A
= Operating Temperature Range
(Note 1)
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
VOLTAGE ERROR AMPLIFIER
Input Voltage Range
0
7
V
Transconductance
V
NON INV
= V
INV
, VEAO = 3.75V
40
70
100
μ
Feedback Reference Voltage
2.4
2.5
2.6
V
Input Bias Current
Note 2
-0.5
-1.0
μA
Output High Voltage
6.0
6.7
V
Output Low Voltage
0.65
1.0
V
Source Current
V
IN
= ±0.5V, V
OUT
= 6V
-40
-90
μA
Sink Current
V
IN
= ±0.5V, V
OUT
= 1.5V
40
90
μA
Open Loop Gain
60
75
dB
PSRR
V
CCZ
- 3V < V
CC
< V
CCZ
- 0.5V
60
75
dB
CURRENT ERROR AMPLIFIER
Input Voltag Range
-1.5
2
V
Transconductance
V
NON INV
= V
INV
, VEAO = 3.75V
130
195
310
μ
Input Offset Voltage
±3
±15
mV
Input Bias Current
-0.5
-1.0
μA
Output High Voltage
6.0
6.7
V
Output Low Voltage
0.65
1.0
V
Source Current
V
IN
= ±0.5V, V
OUT
= 6V
-40
-90
μA
Sink Current
V
IN
= ±0.5V, V
OUT
= 1.5V
40
90
μA
Open Loop Gain
60
75
dB
PSRR
V
CCZ
- 3V < V
CC
< V
CCZ
- 0.5V
60
75
dB
