XC2385A, XC2387A
XC2000 Family / Base Line
Electrical Parameters
Data Sheet
131
V2.1, 2011-07
4.6.7
Debug Interface Timing
The debugger can communicate with the XC238xA either via the 2-pin DAP interface or
via the standard JTAG interface.
Debug via DAP
The following parameters are applicable for communication through the DAP debug
interface.
Note: These parameters are not subject to production test but verified by design and/or
characterization.
Note: Operating Conditions apply;
C
L=20 pF.
Table 38
DAP Interface Timing for Upper Voltage Range
Parameter
Symbol
Values
Unit
Note /
Test Condition
Min.
Typ.
Max.
DAP0 clock period
t
11 SR
25
1)
1) The debug interface cannot operate faster than the overall system, therefore
t
11 ≥ tSYS.
ns
DAP0 high time
t
12 SR
8
ns
DAP0 low time
t
13 SR
8
ns
DAP0 clock rise time
t
14 SR
4ns
DAP0 clock fall time
t
15 SR
4ns
DAP1 setup to DAP0
rising edge
t
16 SR
6
ns
pad_type= stan
dard
DAP1 hold after DAP0
rising edge
t
17 SR
6
ns
pad_type= stan
dard
DAP1 valid per DAP0
clock period
2)
2) The Host has to find a suitable sampling point by analyzing the sync telegram response.
t
19 CC
17
20
ns
pad_type= stan
dard
