9397 750 15057
Koninklijke Philips Electronics N.V. 2005. All rights reserved.
Product data sheet
Rev. 02 — 14 June 2005
26 of 37
Philips Semiconductors
TDA6500; TDA6501
5 V mixer/oscillator and synthesizer for PAL and NTSC standards
Table 32:
Components for measurement circuit
Component
Value
Component
Value
Capacitors; all SMD and NP0, unless otherwise stated
C1
1.8 pF (N750)
C15
100 nF
C2
1.5 pF (N750)
C16
820 pF
C3
82 pF (N750)
C17
4.7 nF
C4
1 pF (N750)
C18
4.7 nF
C5
1.5 pF (N750)
C19
4.7 nF
C6
100 pF (N750)
C20
12 pF
C7
1.2 pF (N750)
C21
12 pF
C8
1.2 pF (N750)
C22
160 nF
C9
1.2 pF (N750)
C23
10 nF
C10
1.2 pF (N750)
C25
10
F (16 V; electrolytic)
C11
27 pF (N750)
C26
10
F (16 V; electrolytic)
C12
4.7 nF
C27
22 pF
C13
4.7 nF
C28
3.9 pF
C14
18 pF
Resistors; all SMD
R1
12
R12
220
R2
5.6
R13
470
R3
27
R14
1 k
R4
5.6 k
R15
2.2 k
R5
22 k
R16
0
R6
22 k
R17
330
R7
5.6 k
R18
330
R10
27 k
R19
18 k
R11
1 k
R20
4.7 k
Diodes and LEDs
D1
BB182
D4
3 mm
D2
BB178
D5
3 mm
D3
BB179
D6
3 mm
D7
3 mm
Coils; including IF coil; wire size 0.4 mm
L1
6 t;
4 mm
L4
2 x 6 t; coil type: TOKO 7kN;
material: 113 kN; screw core:
03-0093; pot core: 04-0026
L2
3 t;
2mm
L3
3 t;
2mm
L5
680 nH
IC, transistor and crystal
IC
TDA6500TT; TDA6501TT
X1
4 MHz
Q1
BC847
