MAX9880A
Low-Power, High-Performance
Dual I2S Stereo Audio Codec
14
______________________________________________________________________________________
ELECTRICAL CHARACTERISTICS (continued)
(VAVDD = VPVDD = VMICVDD = VDVDD = VDVDDS1 = +1.8V, RL =
∞, headphone load (RL) connected between _OUTP and _OUTN, dif-
ferential modes, CREF = 2.2F, CMICBIAS = CPREG = CREG = 1F, AVPRE = +20dB, AVPGAM = 0dB, AVDAC = 0dB, AVLINE = +20dB,
AVVOL = 0dB, AVLO = 0dB, fMCLK = 13MHz, TA = TMIN to TMAX, unless otherwise noted. Typical values are at TA = +25°C.) (Note 2)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Bus Capacitance
CB
400
pF
Pulse Width of
Suppressed Spike
tSP
0
50
ns
SPI TIMING CHARACTERISTICS
Minimum SCLK Clock
Period
tCP
40
ns
Minimum SCLK Pulse-
Width Low
tCL
18
ns
Minimum SCLK Pulse-
Width High
tCH
18
ns
Minimum
CS Setup
Time
tCSS
20
ns
Minimum
CS Hold Time
tCSH
20
ns
Minimum
CS Pulse-
Width High
tCSW
20
ns
Minimum DIN Setup Time
tDS
5
ns
Minimum DIN Hold Time
tDH
5
ns
Minimum Output Data
Propagation Delay
tDO
CL = 50pF
9
ns
Minimum Output Data
Enable Time
tDEN
5
ns
Minimum Output Data
Disable Time
tDZ
5
ns
Note 2:
The MAX9880A is 100% production tested at TA = +25°C. Specifications over temperature limits are guaranteed by
design.
Note 3:
Clocking all zeros into the DAC. Master mode. Differential headphone mode.
Note 4:
DAC performance measured at headphone outputs.
Note 5:
Dynamic range measured using the EIAJ method. -60dBFS 1kHz output signal, A-weighted, and normalized to 0dBFS.
f = 20Hz to 20kHz.
Note 6:
Performance measured using microphone inputs, unless otherwise stated.
Note 7:
Performance measured using line inputs.
Note 8:
Performance measured using line inputs to line outputs.
Note 9:
Performance measured using DAC. fMCLK = 12.288MHz, fLRCLK = 48kHz, unless otherwise stated.
Note 10: LRCLK can be any rate in the indicated range. Asynchronous or noninteger MCLK/LRCLK ratios can exhibit some full-
scale performance degradation compared to synchronous integer-related MCLK/LRCLK ratios.
Note 11: In master-mode operation, the accuracy of the MCLK input proportionally determines the accuracy of the sample clock
rate.
Note 12: CB is in pF.
