參數資料
型號： MC56F8346VFVER2
廠商： Freescale Semiconductor
文件頁數： 6/178頁
文件大小： 0K
描述： IC HYBRID CTRLR 16BIT 144-LQFP
標準包裝： 500
系列： 56F8xxx
核心處理器： 56800E
芯體尺寸： 16-位
速度： 60MHz
連通性： CAN，EBI/EMI，SCI，SPI
外圍設備： POR，PWM，溫度傳感器，WDT
輸入/輸出數： 62
程序存儲器容量： 136KB（68K x 16）
程序存儲器類型： 閃存
RAM 容量： 6K x 16
電壓 - 電源 (Vcc/Vdd)： 2.25 V ~ 3.6 V
數據轉換器： A/D 16x12b
振蕩器型： 外部
工作溫度： -40°C ~ 105°C
封裝/外殼： 144-LQFP
包裝： 帶卷 (TR)
配用： MC56F8367EVME-ND - EVAL BOARD FOR MC56F83X
Register Descriptions
56F8346 Technical Data, Rev. 15
Freescale Semiconductor
103
Preliminary
5.6.13
Fast Interrupt 0 Vector Address Low Register (FIVAL0)
Figure 5-15 Fast Interrupt 0 Vector Address Low Register (FIVAL0)
5.6.13.1
Fast Interrupt 0 Vector Address Low (FIVAL0)—Bits 15–0
The lower 16 bits of the vector address used for Fast Interrupt 0. This register is combined with FIVAH0
to form the 21-bit vector address for Fast Interrupt 0 defined in the FIM0 register.
5.6.14
Fast Interrupt 0 Vector Address High Register (FIVAH0)
Figure 5-16 Fast Interrupt 0 Vector Address High Register (FIVAH0)
5.6.14.1
Reserved—Bits 15–5
This bit field is reserved or not implemented. It is read as 0 and cannot be modified by writing.
5.6.14.2
Fast Interrupt 0 Vector Address High (FIVAH0)—Bits 4–0
The upper five bits of the vector address used for Fast Interrupt 0. This register is combined with FIVAL0
to form the 21-bit vector address for Fast Interrupt 0 defined in the FIM0 register.
5.6.15
Fast Interrupt 1 Match Register (FIM1)
Figure 5-17 Fast Interrupt 1 Match Register (FIM1)
5.6.15.1
Reserved—Bits 15–7
This bit field is reserved or not implemented. It is read as 0, but cannot be modified by writing.
5.6.15.2
Fast Interrupt 1 Vector Number (FAST INTERRUPT 1)—Bits 6–0
This value determines which IRQ will be a Fast Interrupt 1. Fast interrupts vector directly to a service
Base + $C
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Read
FAST INTERRUPT 0
VECTOR ADDRESS LOW
Write
RESET
00000
0000000
0000
Base + $D
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Read
0
FAST INTERRUPT 0
VECTOR ADDRESS HIGH
Write
RESET
00000
0000000
0000
Base + $E
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Read
0
FAST INTERRUPT 1
Write
RESET
00000
0000000
0000
