Semiconductor
MSM6786
1/16
1/3, 1/4 DUTY LCD DRIVER WITH 4-DOT COMMON DRIVER AND 29-DOT SEGMENT DRIVER
GENERAL DESCRIPTION
The MSM6786 is a dynamic display LCD driver and can be switched to 1/3 or 1/4 duty. It can
dis-play up to 116 segments with 1/4 duty and up to 87 segments with 1/3 duty. It can also drive
one LED directly. The built-in 5
￥
6 key circuit allows input through a keyboard, and minimizes
the number of wires between the front panel and CPU.
FEATURES
Power suppy voltage
Operating temperature
29-output segment driver
1/4 duty dynamic drive
1/3 duty dynamic drive
One LED can be driven directly (I
O
=–15mA max)
Built-in 5
￥
6 key scan circuit allows reading of the operation status of up to 30 switches.
Interface with CPU is implemented by LOAD, DATA I/O and CLOCK in serial method.
Built-in RC oscillator for LCD AC drive
Built-in voltage dividing resistor for bias voltage generation
Package:
56-pin plastic QFP (QFP56-P-910-0.65-2K) (Product name : MSM6786GS-2K)
: 5V
±
10%
: –40 to +85
°
C
: Up to 116 segments can be displayed
: Up to 87 segments can be displayed
E2B0013-27-Y3
This version: Nov. 1997
Previous version: Mar. 1996
