SLAS697A
– MARCH 2010 – REVISED FEBRUARY 2011
TERMINAL FUNCTIONS (64-PM PACKAGE) (continued)
TERMINAL
I/O
DESCRIPTION
NAME
PM
General-purpose digital I/O pin/Timer_B, capture: CCI3A/B input, compare:
P4.3/TB3
39
I/O
Out3 output
General-purpose digital I/O pin/Timer_B, capture: CCI4A/B input, compare:
P4.4/TB4
40
I/O
Out4 output
General-purpose digital I/O pin/Timer_B, capture: CCI5A/B input, compare:
P4.5/TB5
41
I/O
Out5 output
General-purpose digital I/O pin/Timer_B, capture: CCI6A input, compare:
P4.6/TB6
42
I/O
Out6 output
P4.7/TBCLK
43
I/O
General-purpose digital I/O pin/Timer_B, clock signal TBCLK input
General-purpose digital I/O pin/USCI B1 slave transmit enable/USCI A1
P5.0/UCB1STE/UCA1CLK
44
I/O
clock input/output
General-purpose digital I/O pin/USCI B1slave in/master out in SPI mode,
P5.1/UCB1SIMO/UCB1SDA
45
I/O
SDA I2C data in I2C mode
General-purpose digital I/O pin/USCI B1slave out/master in in SPI mode,
P5.2/UCB1SOMI/UCB1SCL
46
I/O
SCL I2C clock in I2C mode
General-purpose digital I/O/USCI B1 clock input/output, USCI A1 slave
P5.3/UCB1CLK/UCA1STE
47
I/O
transmit enable
P5.4/MCLK
48
I/O
General-purpose digital I/O pin/main system clock MCLK output
P5.5/SMCLK
49
I/O
General-purpose digital I/O pin/submain system clock SMCLK output
P5.6/ACLK
50
I/O
General-purpose digital I/O pin/auxiliary clock ACLK output
General-purpose digital I/O pin/switch all PWM digital output ports to high
P5.7/TBOUTH/SVSOUT
51
I/O
impedance -- Timer_B TB0 to TB6/SVS comparator output
P6.0/A0
59
I/O
General-purpose digital I/O pin/analog input A0
– 12-bit ADC
P6.1/A1
60
I/O
General-purpose digital I/O pin/analog input A1
– 12-bit ADC
P6.2/A2
61
I/O
General-purpose digital I/O pin/analog input A2
– 12-bit ADC
P6.3/A3
2
I/O
General-purpose digital I/O pin/analog input A3
– 12-bit ADC
P6.4/A4
3
I/O
General-purpose digital I/O pin/analog input A4
– 12-bit ADC
General-purpose digital I/O pin/analog input A5
– 12-bit ADC/DAC12.1
P6.5/A5/DAC1
4
I/O
output
General-purpose digital I/O pin/analog input A6
– 12-bit ADC/DAC12.0
P6.6/A6/DAC0
5
I/O
output
General-purpose digital I/O pin/analog input a7
– 12-bit ADC/DAC12.1
P6.7/A7/DAC1/SVSIN
6
I/O
output/SVS input
P7.0
NC
I/O
General-purpose digital I/O pin
P7.1
NC
I/O
General-purpose digital I/O pin
P7.2
NC
I/O
General-purpose digital I/O pin
P7.3
NC
I/O
General-purpose digital I/O pin
P7.4
NC
I/O
General-purpose digital I/O pin
P7.5
NC
I/O
General-purpose digital I/O pin
P7.6
NC
I/O
General-purpose digital I/O pin
P7.7
NC
I/O
General-purpose digital I/O pin
P8.0
NC
I/O
General-purpose digital I/O pin
P8.1
NC
I/O
General-purpose digital I/O pin
P8.2
NC
I/O
General-purpose digital I/O pin
P8.3
NC
I/O
General-purpose digital I/O pin
P8.4
NC
I/O
General-purpose digital I/O pin
P8.5
NC
I/O
General-purpose digital I/O pin
P8.6/XT2OUT
NC
O
General-purpose digital I/O pin/Output terminal of crystal oscillator XT2
General-purpose digital I/O pin/Input port for crystal oscillator XT2. Only
P8.7/XT2IN
NC
I
standard crystals can be connected.
2010–2011, Texas Instruments Incorporated
7
Product Folder Link(s): MSP430F2619S-HT
