SN54ABTH18652A, SN54ABTH182652A, SN74ABTH18652A, SN74ABTH182652A
SCAN TEST DEVICES WITH
18-BIT BUS TRANSCEIVERS AND REGISTERS
SCBS167D – AUGUST 1993 – REVISED JULY 1996
13
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
device-identification register
The device-identification register (IDR) is 32 bits long. It can be selected and read to identify the manufacturer,
part number, and version of this device.
For the ’ABTH18652A , the binary value 00000000000000101010000000101111 (0002A02F, hex) is captured
(during Capture-DR state) in the IDR to identify this device as Texas Instruments SN54/74ABTH18652A.
For the ’ABTH182652A , the binary value 00000000000000101110000000101111 (0002E02F, hex) is captured
(during Capture-DR state) in the IDR to identify this device as Texas Instruments SN54/74ABTH182652A.
The IDR order of scan is from TDI through bits 31–0 to TDO. Table 2 shows the IDR bits and their significance.
Table 2. Device-Identification Register Configuration
IDR BIT
NUMBER
IDENTIFICATION
SIGNIFICANCE
IDR BIT
NUMBER
IDENTIFICATION
SIGNIFICANCE
IDR BIT
NUMBER
IDENTIFICATION
SIGNIFICANCE
MANUFACTURER10
MANUFACTURER09
MANUFACTURER08
MANUFACTURER07
MANUFACTURER06
MANUFACTURER05
MANUFACTURER04
MANUFACTURER03
MANUFACTURER02
MANUFACTURER01
MANUFACTURER00
LOGIC1
31
VERSION3
27
PARTNUMBER15
11
30
VERSION2
26
PARTNUMBER14
10
29
VERSION1
25
PARTNUMBER13
9
28
VERSION0
24
PARTNUMBER12
8
––
––
23
PARTNUMBER11
7
––
––
22
PARTNUMBER10
6
––
––
21
PARTNUMBER09
5
––
––
20
PARTNUMBER08
4
––
––
19
PARTNUMBER07
3
––
––
18
PARTNUMBER06
2
––
––
17
PARTNUMBER05
1
––
––
16
PARTNUMBER04
0
––
––
15
PARTNUMBER03
––
––
––
––
14
PARTNUMBER02
––
––
––
––
13
PARTNUMBER01
––
––
––
––
12
PARTNUMBER00
––
––
Note that for TI products, bits 11–0 of the device-identification register always contain the binary value 000000101111
(02F, hex).
