HV7131B
Electronics Industries Co., Ltd.
System IC Division
CMOS IMAGE SENSOR
With 8-bit ADC
This document is a general product description and is subject to change without notice. Hyundai Electronics does not assume any
responsibility for use of circuits described. NO patent licenses are implied.
DA31991011R_1.0 - 3 - 1999 Hyundai System IC Division
PRELIMINARY
ELECTRO-OPTICAL CHARACTERISTICS
color temperature of light source: 3200K / IR cut-off filter (CM-500S, 1mmt) is used.
Parameter
Units
Sensitivity
mV / lux
sec
Dark Signal
mV/sec
Output Saturation Signal
mV
Dynamic Range
dB
Output Signal Shading
%
Dark Signal Shading
mV/sec
Frame Rate
fps
Min.
1600
-
1200
-
-
-
-
Typical
2200
-
-
-
8
-
-
Max.
-
Note
1)
2)
3)
4)
5)
6)
7)
50
-
48
13
10
45
Note:
1) Measured at 28lux illumination for exposure time 10 ms.
2) Measured at zero illumination for exposure time 50 ms. (T
temp
= 40 Centigrade)
3) Measured at V
dd
=3.3V and 100lux illumination for exposure time 50msec.
4) 48dB is limited by 8-bit ADC.
5) Variance of average value of 4x4 pixels response of each block over all equal blacks at 50%
saturation level illumination for exposure time 10msec.
6) Range between V
max
and V
min
at zero illumination for exposure time 50msec, where V
max
and V
min
are the maximum and minimum values of each block’ s response, respectively.
7) Measured at MCLK 15MHz.
Integration time must be set in order for effective window height not to exceed window height.
It’s because effective window height is directly proportional to integration time.
