IDT82P5088
UNIVERSAL OCTAL T1/E1/J1 LIU WITH INTEGRATED CLOCK ADAPTER
PROGRAMMING INFORMATION
47
February 5, 2009
4.3.4
RECEIVE PATH CONTROL REGISTERS
Table-44 RJACF: Jitter Attenuator Configuration Register for Receive Path
(R/W, Address = X27H)
Symbol
Bit
Default
Description
-
7-6
00
Reserved
RJITT_TEST
5
0
This bit selects jitter measure mode
= 0: real time mode (update jitter measuring value each received clock cycle)
= 1: accumulation mode (measuring p-p value of jitter since last read)
RJA_LIMIT
4
1
Wide Jitter Attenuation bandwidth
= 0: normal mode
= 1: JA limit mode
RJA_E
3
00
Jitter Attenuator configuration
= 0: JA not used
= 1: JA enabled
RJA_DP[1:0]
2-1
00
Jitter Attenuator depth selection
= 00: 128 bits
= 01: 64 bits
= 10/11: 32 bits
RJA_BW
0
Jitter transfer function bandwidth selection
JABW
T1/J1
E1
0
5 Hz
6.77 Hz
1
1.26 Hz
0.87 Hz
Table-45 RCF0: Receiver Configuration Register 0 for Receive Path
(R/W, Address = X28H)
Symbol
Bit
Default
Description
-
7-5
000
Reserved
R_OFF
4
0
Receiver power down enable
= 0: Receiver power up
= 1: Receiver power down
RD_INV
3
0
Receive data invert
= 0: data on RDn or RDPn/RDNn is active high
= 1: data on RDn or RDPn/RDNn is active low
RCLK_SEL
2
0
Receive clock edge select (this bit is ignored in slicer mode)
= 0: data on RDn or RDPn/RDNn is updated on the rising edges of RCLKn
= 1: data on RDn or RDPn/RDNn is updated on the falling edges of RCLKn
R_MD[1:0]
1-0
00
Receiver path decoding selection
= 00: receive data is HDB3 (E1) / B8ZS (T1/J1) decoded and output on RDn with single rail NRZ format
= 01: receive data is AMI decoded and output on RDn with single rail NRZ format
= 10: decoder is bypassed, re-timed dual rail data with NRZ format output on RDPn/RDNn (dual rail mode with
clock recovery)
= 11: both CDR and decoder blocks are bypassed, slicer data with RZ format output on RDPn/RDNn (slicer mode)
