Table 13. MR5—Autonegotiation Link Partner (LP) Ability Register Bit Descriptions (Base_Page)
1. Note that the format for the pin descriptions is as follows: the first number is the register number, the second number is the bit position in the
register, and the name of the instantiated pad is in capital letters.
2. R = read.
Table 14. MR5—Autonegotiation Link Partner (LP) Ability Register Bit Descriptions (Next_Page)
1. Note that the format for the pin descriptions is as follows: the first number is the register number, the second number is the bit position in the
register, and the name of the instantiated pad is in capital letters.
2. R = read.
Bit
1
Type
2
R
Description
5.15 (LP_NEXT_PAGE)
Link Partner Next Page.
When this bit is set to 1, it indicates that the link
partner wishes to engage in next page exchange.
Link Partner Acknowledge.
When this bit is set to 1, it indicates that the link
partner has successfully received at least three consecutive and consistent
FLP bursts.
Link Partner Remote Fault.
When this bit is set to 1, it indicates that the link
partner has a fault.
Reserved.
These bits are reserved.
Link Partner 100Base-T4.
When this bit is set to 1, it indicates that link part-
ner is capable of 100Base-T4 operation.
Link Partner 100Base-TX Full Duplex.
When this bit is set to 1, it indicates
that link partner is capable of 100Base-TX full-duplex operation.
Link Partner 100Base-TX.
When this bit is set to 1, it indicates that link part-
ner is capable of 100Base-TX operation.
Link Partner 10Base-T Full Duplex.
When this bit is set to 1, it indicates that
link partner is capable of 10Base-T full-duplex operation.
Link Partner 10Base-T.
When this bit is set to 1, it indicates that link partner
is capable of 10Base-T operation.
Selector Field.
This field contains the type of message sent by the link part-
ner. For IEEE802.3 compliant link partners, this field should read 00001.
5.14 (LP_ACK)
R
5.13 (LP_REM_FAULT)
R
5.12:10
R
R
5.9 (LP_100BASET4)
5.8 (LP_100BASET_FD)
R
5.7 (LP_100BASETX)
R
5.6 (LP_10BASET_FD)
R
5.5 (LP_10BASET)
R
5.4:0 (LP_SELECT)
R
Bit
1
Type
2
R
Description
5.15 (LP_NEXT_PAGE)
Next Page.
When this bit is set to a logic 0, it indicates that this is the last
page to be transmitted. A logic 1 indicates that additional pages will follow.
Acknowledge.
When this bit is set to a logic 1, it indicates that the link part-
ner has successfully received its partner’s link code word.
Message Page.
This bit is used by the Next_Page function to differentiate a
Message Page (logic one) from an unformatted page (logic zero).
Acknowledge 2.
This bit is used by Next_Page function to indicate that a
device has the ability to comply with the message (logic one) or not (logic
zero).
Toggle.
This bit is used by the arbitration function to ensure synchronization
with the link partner during next page exchange. Logic 0 indicates that the
previous value of the transmitted link code word was logic 1. Logic 1 indicates
that the previous value of the transmitted link code word was logic 0.
Message/Unformatted Code Field.
With these 11 bits, there are 2048 possi-
ble messages. Message code field definitions are described in annex 28C of
the IEEE802.3u standard.
5.14 (LP_ACK)
R
5.13 (LP_MES_PAGE)
R
5.12 (LP_ACK2)
R
5.11 (LP_TOGGLE)
R
5.10:0 (MCF)
R
