Developmental Data Sheet
1 of 4
2004-03-17
Typical EDGE EVM Performance
V
DD
= 28 V, I
DQ
= 2.2 A, f = 1989.1 MHz
0
1
2
3
4
30
35
40
45
50
55
Output Power (dBm)
E
.
0
5
10
15
20
25
30
35
40
D
EVM
Efficiency
Advance Information
PTF191601
LDMOS RF Power Field Effect Transistor
160 W, 1930 – 1990 MHz
Features
Broadband internal matching
Typical EDGE performance
- Average output power = 62 W
- Gain = 14 dB
- Efficiency = 32%
- EVM = 1.7%
Typical CW performance
- Output power at P–1dB = 180 W
- Gain = 13 dB
- Efficiency = 47%
Integrated ESD protection: Human Body
Model, Class 1 (minimum)
Excellent thermal stability
Low HCI drift
Capable of handling 10:1 VSWR @ 28 V,
160 W (CW) output power
ESD:
Electrostatic discharge sensitive device—observe handling precautions!
Description
The PTF191601 is a 160 W, internally matched
GOLDMOS
FET intended
for GSM and EDGE applications in the 1930 to 1990 MHz band. Full gold
metallization ensures excellent device lifetime and reliability.
PTF191601E
Package 30260
RF Characteristics
at T
CASE
= 25°C unless otherwise indicated
EDGE Measurements
(not subject to production test—verified by design/characterization in Infineon test fixture)
V
DD
= 28 V, I
DQ
= 2.2 A, P
OUT
= 62 W, f = 1989.8 MHz
Characteristic
Error Vector Magnitude
Modulation Spectrum @ 400 kHz
Modulation Spectrum @ 600 kHz
Gain
Drain Efficiency
Symbol
EVM (RMS)
ACPR
ACPR
G
ps
η
D
Min
—
—
—
—
—
Typ
1.7
–60
–73
14
32
Max
—
—
—
—
—
Units
%
dBc
dBc
dB
%
Two–Tone Measurements
(tested in Infineon test fixture)
V
DD
= 28 V, I
DQ
= 2.2 A, P
OUT
= 160 W PEP, f = 1990 MHz, tone spacing = 1 MHz
Characteristic
Gain
Drain Efficiency
Intermodulation Distortion
Symbol
G
ps
η
D
IMD
Min
—
—
—
Typ
14
36
–30
Max
—
—
—
Units
dB
%
dBc
