SBAS387A – MAY 2009 – REVISED JUNE 2010
www.ti.com
6.2.109 Page 0 / Register 115:
Analog FIR Control Register 2
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D4
R/W
0011
Unit Delay Register for tap 3 in DAC AFIR.
D3–D0
R/W
0010
Unit Delay Register for tap 2 in DAC AFIR.
6.2.110 Page 0 / Register 116:
Analog FIR Control Register 3
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D4
R/W
0101
Unit Delay Register for tap 5 in DAC AFIR.
D3–D0
R/W
0100
Unit Delay Register for tap 4 in DAC AFIR.
6.2.111 Page 0 / Register 117-119:
Reserved Registers
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R
0000 0000
Reserved. Write only default values
6.2.112 Page 0 / Register 120:
GPIO1 Control Register
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D6
R
00
Reserved. Write only default values
D5–D2
R/W
00 00
GPIO1 Control
0000: GPIO1 input/output disabled
0001: GPIO1 input is used for secondary BCLK, secondary WCLK, secondary DIN, secondary
ADC_WCLK or seconday DIGMIC_DATA input
0010: GPIO1 is general purpose input (GPI)
0011: GPIO1 is general purpose output
0100: GPIO1 output is CLKOUT
0101: GPIO1 output is INT1 (active high)
0110: GPIO1 output is inverted INT1 (active low)
0111: GPIO1 output is INT1 (open drain)
1000: GPIO1 output is INT2 (active high)
1001: GPIO1 output is inverted INT2 (active low)
1010: GPIO1 output is INT2 (open drain)
1011: GPIO1 output is ADC_WCLK for Audio Interface
1100: GPIO1 output is secondary bit-clock for Audio Interface
1101: GPIO1 output is secondary word-clock for Audio Interface
1110: GPIO1 output is clock for the digital microphone
1111: Reserved
D1
R
X
GPIO1 Input Pin state as a GPI
D0
R/W
0
GPIO1 as general purpose output control
0: GPIO1 pin is driven to '0' in general purpose output mode
1: GPIO1 pin is driven to '1' in general purpose output mode
6.2.113 Page 0 / Register 121:
GPIO2 Control Register
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D6
R
00
Reserved. Write only default values
118
REGISTER MAP
Copyright 2009–2010, Texas Instruments Incorporated
Product Folder Link(s): TLV320AIC36
