4
MASTER DATA SHEET - Rev 2.1
10/2008
AWT6132R
Table 4: Electrical Specifications – CDMA Operation
(TC = +25 OC, VCC = +3.4 V, VREF = +2.90 V, 50 system)
Notes:
(1) POUT is derated by 0.5 dB for IS-98 / CDMA 2000 operation.
(2) ACPR and Efficiency Measured at 415 MHz.
PARAMETER
MIN
TYP MAX
UNIT
COMMENTS
Gain
26
25
28
27
31
29
dB
POUT = +29.5 dBm, VMODE = 0 V
POUT = +16 dBm, VMODE = +2.90 V
Gain Variation
-
0.4
1.0
dB
Adjacent Channel Power
at 885 kHz offset (1)
Primary Channel BW = 1.23 MHZ
Adjacent Channel BW = 30 kHz
-
-52
-57
-46.5
-47
dB
POUT = +29.5 dBm, VMODE = 0 V
POUT = +16 dBm, VMODE = +2.90 V
Adjacent Channel Power
at 1.98 MHz offset (1)
Primary Channel BW = 1.23 MHZ
Adjacent Channel BW = 30 kHz
-
-62
-67
-59
dB
POUT = +29.5 dBm, VMODE = 0 V
POUT = +16 dBm, VMODE = +2.90 V
Power-Added Efficiency (1)
33
6
35
7
-
%
POUT = +29.5 dBm, VMODE = 0 V
POUT = +16 dBm, VMODE = +2.90 V
Quiescent Current (Icq)
-
60
80
mA
through VCC pins, VMODE = +2.90 V
Reference Current
-
6.5
9
mA
through VREF pin, PA "on"
Mode Control Current
-
0.8
1.0
mA
through VMODE pin,
VMODE = +2.90 V
Leakage Current
-
<1
5
A
VCC = +4.2 V, VREF = 0 V,
VMODE = 0 V
Noise in Receive Band
-
-132
-130
dBm/Hz fO +10 MHz, POUT < +29.5 dBm
Harmonics
2fo
3fo, 4fo
-
-36
-45
-30
-35
dBc
POUT < +29.5 dBm
Input Impedance
-
2:1
VSWR
Spurious Output Level
(all spurious outputs)
-
-70
dBc
POUT < +29.5 dBm
In-band Load VSWR < 5:1
Out-of-band Load VSWR < 10:1
Applies over all operating ranges
Load mismatch stress with no
permanent degradation or failure
10:1
-
VSWR Applies over all operating ranges
