PI7C9X20505GP
5Port-5Lane PCI Express Switch
GreenPacket
TM Family
Datasheet
Page 51 of 81
June 2009 – Revision 1.5
Pericom Semiconductor
BIT
FUNCTION
TYPE
DESCRIPTION
4
EEPROM Autoload
Status
RO
0b: EEPROM autoload was unsuccessful or is disabled
1b: EEPROM autoload occurred successfully after PREST. Configuration
registers were loaded with values stored in the EEPROM
Reset to 0b.
5
EEPROM Autoload
Disable
RW
0b: EEPROM autoload enabled
1b: EEPROM autoload disabled
Reset to 1b.
7:6
EEPROM Clock
Rate
RW
Determines the frequency of the EEPROM clock, which is derived from the
primary clock.
00b: Reserved
01b: PEXCLK / 1024 (PEXCLK is 125MHz)
10b: Reserved
11b: Test Mode
Reset to 01b.
7.2.60
EEPROM ADDRESS REGISTER – OFFSET DCh (Upstream Port Only)
BIT
FUNCTION
TYPE
DESCRIPTION
8
Reserved
RO
Reset to 0b.
15:9
EEPROM Address
RW
Contains the EEPROM address.
Reset to 0.
7.2.61
EEPROM DATA REGISTER – OFFSET DCh (Upstream Port Only)
BIT
FUNCTION
TYPE
DESCRIPTION
31:16
EEPROM Data
RW
Contains the data to be written to the EEPROM. After completion of a read
cycle, this register will contain the data from the EEPROM.
Reset to 0000h.
7.2.62
PCI EXPRESS CAPABILITY ID REGISTER – OFFSET E0h
BIT
FUNCTION
TYPE
DESCRIPTION
7:0
Enhanced
Capabilities ID
RO
Read as 10h to indicate that these are PCI express enhanced capability
registers.
7.2.63
NEXT ITEM POINTER REGISTER – OFFSET E0h
BIT
FUNCTION
TYPE
DESCRIPTION
15:8
Next Item Pointer
RO
Read as 00h. No other ECP registers.
7.2.64
PCI EXPRESS CAPABILITIES REGISTER – OFFSET E0h
BIT
FUNCTION
TYPE
DESCRIPTION
19:16
Capability Version
RO
Read as 0001b to indicate the device is compliant to Revision 1.0a of PCI
Express Base Specifications.
