PM5352 S/UNI STAR
DATA SHEET
PMC-1990421
ISSUE 2
SATURN USER NETWORK INTERFACE 155 (STAR)
PROPRIETARY AND CONFIDENTIAL TO PMC-SIERRA, INC., AND FOR ITS CUSTOMERS’ INTERNAL USE
37
Pin Name
Type
Pin
No.
Function
TRSTB
Input
pull-up
C9
The active-low test reset (TRSTB) signal provides
an asynchronous S/UNI-STAR test access port
reset via the IEEE P1149.1 test access port.
TRSTB is a Schmitt triggered input with an integral
pull-up resistor.
Note that when not being used, TRSTB must be
connected to the RSTB input.
6.6 Analog Signals
Pin Name
Type
Pin
No.
Function
C+
C-
Analog
AB4
AA5
The analog CP and CN pins are provided for
applications that must meet SONET/SDH jitter
transfer specifications. A TBD nF ceramic capacitor
can be attached across C+ and C-.
ATB0
ATB1
ATB2
ATB3
Analog I/O P2
P3
P4
R1
The Analog Test Bus (ATB). These pins are used
for manufacturing testing only and should be
connected ground.
6.7 Power and Ground
Pin Name
Type
Pin
No.
Function
BIAS
Bias
Voltage
K21
C17
I/O Bias (BIAS). When tied to +5V via a 1 K
resistor, the BIAS input is used to bias the wells in
the input and I/O pads so that the pads can tolerate
5V on their inputs without forward biasing internal
ESD protection devices. When BIAS is tied to
+3.3V, the inputs and bi-directional inputs will only
tolerate 3.3V level inputs.
This Material Copyrighted by Its Respective Manufacturer
