W83C553F
1.2
The W83C553F Enhanced System I/O (SIO) Controller with PCI Arbiter is a highly integrated device intended for use in any
Peripheral Component Interconnect (PCI) system, supporting x86 or PowerPC (non-x86) type microprocessors. It supports
all PCI 2.1 compliant CPU bridge implementations and directly interfaces with PCI and ISA industry standard buses,
including two direct drive IDE channels supporting up to four peripherals.
The W83C553F is a universal PCI device which can be used with many CPU-to-PCI bridge solution. The W83C553F
includes 32-bit ISA DMA addressing (rather than 24-bit) to simplify its use in systems using re-compiled versions of 32-bit
operating systems (such as Windows NT running on PowerPC, Alpha, or other RISC CPU).
The peripheral controller integrated into the W83C553F includes two enhanced seven channel 82C37A 32-bit DMA
controllers that support fast DMA transfers with a four byte line buffer to isolate the PCI bus from the ISA bus, enhancing
performance. Both DMA controllers support scatter/gather data transfer capability.
The W83C553F Enhanced SIO controller provides the bridge between the PCI bus and the ISA expansion bus. It also
integrates a PCI bus master IDE controller, an eight master PCI arbiter (which may be disabled if desired) and many of the
common I/O functions found in today's ISA based PC systems. The W83C553F incorporates the logic for a complete PCI
interface (master and slave) and ISA interface (master and slave). Also included is PCI and ISA arbitration, 14 level interrupt
controller, a 16-bit BIOS timer, three programmable counter/timers, non-maskable-interrupt (NMI) control logic and register
support for power management break events.
The built-in Enhanced PCI IDE Controller is a highly integrated dual port controller, providing a high performance data path
between IDE devices and the PCI bus. Four IDE chip select signals provide accessing of up to four devices. Each device has
its own programmable registers for selecting 16-bit and 32-bit data pipelined transfer rates, read-ahead and posted writes. A
large 64 Byte DMA FIFO buffers data to and from the IDE disks enabling the integrated scatter/gather DMA controller to
efficiently perform zero wait state burst transfers across the PCI bus when enough data is available in the FIFO. Bus master
IDE significantly improves the overall system performance of a multi-master PCI configuration by greatly reducing the bus
and CPU utilization required for the disk and CD-ROM interface. Burst data transfers at 33 MHz can be sustained at 132
MB/s on the PCI bus.
The integrated bus-mastering PCI-IDE core is the original Sonata W83789F core with some modification of interrupt routing.
This controller is fully compliant to Intel's Bus-Mastering Controller and SFF8038i specifications. BIOS support has been
incorporated in all the leading BIOS companies' software. Driver software, previously tested and qualified for the W83789F,
is available from Winbond Systems Laboratory for all major operating systems, including recompiled PowerPC versions.
General Information
WINBOND SYSTEMS LABORATORY
7
General Description
