WM8731
Advanced Information
WOLFSON MICROELECTRONICS LTD
AI Rev 2.0 February 2001
41
The exact sample rates supported for all combinations are defined by the relationships in Table 21
below.
ACTUAL SAMPLING RATE
BOSR=0
( 250fs)
kHz
8
TARGET
SAMPLING
RATE
BOSR=1
(272fs)
kHz
8.021
kHz
8
12MHz/(250 x 48/8)
32
12MHz/(272 x 11/2)
not available
32
12MHz/(250 x 48/32)
not available
44.117
44.1
12MHz/272
not available
48
48
12MHz/250
not available
88.235
88.2
12MHz/136
not available
96
96
12MHz/125
Table 21 USB Mode Actual Sample Rates
ACTIVATING DSP AND DIGITAL AUDIO INTERFACE
To prevent any communication problems from arising across the Digital Audio Interface the Audio
Interface is disabled (tristate with weak 100k pulldown). Once the Audio Interface and the Sampling
Control has been programmed it is activated by setting the ACTIVE bit under Software Control.
REGISTER
ADDRESS
0001001
Active Control
BIT
LABEL
DEFAULT
DESCRIPTION
0
ACTIVE
0
Activate Interface
1 = Active
0 = Inactive
Table 22 Activating DSP and Digital Audio Interface
It is recommended that between changing any content of Digital Audio Interface or Sampling Control
Register that the active bit is reset then set.
SOFTWARE CONTROL INTERFACE
The software control interface may be operated using either a 3-wire (SPI-compatible) or 2-wire MPU
interface. Selection of interface format is achieved by setting the state of the MODE pin.
In 3-wire mode, SDIN is used for the program data, SCLK is used to clock in the program data and
CSB is used to latch in the program data. In 2-wire mode, SDIN is used for serial data and SCLK is
used for the serial clock. In 2-wire mode, the state of CSB pin allows the user to select one of two
addresses.
SELECTION OF SERIAL CONTROL MODE
The serial control interface may be selected to operate in either 2 or 3-wire modes. This is achieved
by setting the state of the MODE pin.
MODE
INTERFACE
FORMAT
2 wire
3 wire
0
1
Table 23 Control Interface Mode Selection
