參數資料
型號： XWM8731EDS
廠商： Wolfson Microelectronics
元件分類： Codec
英文描述： Portable Internet Audion CODEC with Headphone Driver and Programmable Sample Rates
中文描述： 便攜式互聯網三極管編解碼器的耳機驅動器和可編程采樣率
文件頁數： 46/56頁
文件大小： 595K
代理商： XWM8731EDS
WM8731
Advanced Information
WOLFSON MICROELECTRONICS LTD
AI Rev 2.0 February 2001
46
REGISTER
ADDRESS
0000000
Left Line In
BIT
LABEL
DEFAULT
DESCRIPTION
4:0
LINVOL[4:0]
10111
( 0dB )
Left Channel Line Input Volume
Control
11111 = +12dB . . 1.5dB steps down
to 00000 = -34.5dB
Left Channel Line Input Mute to ADC
1 = Enable Mute
0 = Disable Mute
Left to Right Channel Line Input
Volume and Mute Data Load Control
1 = Enable Simultaneous Load of
LINVOL[4:0] and LINMUTE to
RINVOL[4:0] and RINMUTE
0 = Disable Simultaneous Load
Right Channel Line Input Volume
Control
11111 = +12dB . .1.5dB steps down
to 00000 = -34.5dB
Right Channel Line Input Mute to
ADC
1 = Enable Mute
0 = Disable Mute
Right to Left Channel Line Input
Volume and Mute Data Load Control
1 = Enable Simultaneous Load of
RINVOL[4:0] and RINMUTE to
LINVOL[4:0] and LINMUTE
0 = Disable Simultaneous Load
Left Channel Headphone Output
Volume Control
1111111 = +6dB
. . 1dB steps down to
0110000 = -73dB
0000000 to 0101111 = MUTE
Left Channel Zero Cross detect
Enable
1 = Enable
0 = Disable
Left to Right Channel Headphone
Volume, Mute and Zero Cross Data
Load Control
1 = Enable Simultaneous Load of
LHPVOL[6:0] and LZCEN to
RHPVOL[6:0] and RZCEN
0 = Disable Simultaneous Load
7
LINMUTE
1
8
LRINBOTH
0
4:0
RINVOL[4:0]
10111
( 0dB )
7
RINMUTE
1
0000001
Right Line In
8
RLINBOTH
0
6:0
LHPVOL
[6:0]
1111001
( 0dB )
7
LZCEN
0
0000010
Left Headphone
Out
8
LRHPBOTH
0
