IDT82V2082
DUAL CHANNEL T1/E1/J1 LONG HAUL/SHORT HAUL LINE INTERFACE UNIT
PROGRAMMING INFORMATION
48
May 4, 2009
4.3.2
TRANSMIT AND RECEIVE TERMINATION REGISTER
4.3.3
JITTER ATTENUATION CONTROL REGISTER
Table-29 TERM: Transmit and Receive Termination Configuration Register
(R/W, Address = 02H, 22H)
Symbol
Bit
Default
Description
-
7-6
00
Reserved.
T_TERM[2:0]
5-3
000
These bits select the internal termination for transmit line impedance matching.
= 000: Internal 75
impedance matching
= 001: Internal 120
impedance matching
= 010: Internal 100
impedance matching
= 011: Internal 110
impedance matching
= 1xx: Selects external impedance matching resistors for E1 mode only. T1/J1 does not require external impedance
resistors (see Table-14).
R_TERM[2:0]
2-0
000
These bits select the internal termination for receive line impedance matching.
= 000: Internal 75
impedance matching
= 001: Internal 120
impedance matching
= 010: Internal 100
impedance matching
= 011: Internal 110
impedance matching
= 1xx: Selects external impedance matching resistors (see Table-15).
Table-30 JACF: Jitter Attenuation Configuration Register
(R/W, Address = 03H, 23H)
Symbol
Bit
Default
Description
-
7-6
00
Reserved.
JA_LIMIT
5
1
= 0: Normal mode
= 1: JA limit mode
JACF[1:0]
4-3
00
Jitter Attenuation configuration
= 00/10: JA not used
= 01: JA in transmit path
= 11: JA in receive path
JADP[1:0]
2-1
00
Jitter Attenuation depth select
= 00: 128 bits
= 01: 64 bits
= 1x: 32 bits
JABW
0
Jitter transfer function bandwidth select
= 0: 6.8 Hz (E1)
5 Hz (T1/J1)
= 1: 0.9 Hz (E1)
1.25 Hz (T1/J1)
相關PDF資料
PDF描述
IDT82V2084PFG IC LIU T1/J1/E1 4CH 128-TQFP
IDT82V2088DRG IC LIU T1/J1/E1 8CH 208-TQFP
IDT82V2108BBG IC FRAMER T1/J1/E1 8CH 144-BGA
IDT82V2604BBG IC INVERSE MUX 4CH ATM 208-BGA
IDT82V2608BBG IC INVERSE MUX 8CH ATM 208-BGA
