Philips Semiconductors
ISP1760
Embedded Hi-Speed USB host controller
41 to 35
DeviceAddress
[6:0]
EndPt[3:1]
SW —
writes
Device Address
: This is the USB address of the function containing the
endpoint that is referred to by the buffer.
Endpoint
: This is the USB address of the endpoint within the function.
34 to 32
DW0
31
30 to 29
SW —
writes
EndPt[0]
Mult[1:0]
SW —
writes
SW —
writes
Endpoint
: This is the USB address of the endpoint within the function.
Multiplier
: This field is a multiplier counter used by the Host Controller as
the number of successive packets the Host Controller may submit to the
endpoint in the current execution.
Set this field to 01b. You can also set it to 11b and 10b depending on your
application. 00b is undefined.
Maximum Packet Length
: This field indicates the maximum number of
bytes that can be sent to or received from the endpoint in a single data
packet.
Number of Bytes to Transfer
: This field indicates the number of bytes can
be transferred by this data structure. It is used to indicate the depth of the
DATA field (32 kbytes).
-
Valid
:
0 —
This bit is deactivated when the entire PTD is executed—across
μ
SOF
and SOF—or when a fatal error is encountered.
1 —
Software updates to one when there is payload to be sent or received
even across ms boundary. The current PTD is active.
28 to 18
MaxPacket
Length[10:0]
SW —
writes
17 to 3
NrBytesTo
Transfer[14:0]
SW —
writes
2 to 1
0
reserved
V
-
SW —
sets
HW —
resets
Table 69:
Bit
High-speed interrupt IN and OUT, QHP: bit description
…continued
Symbol
Access
Description
