3-4
MC92600 SERDES User’s Manual
MOTOROLA
Alignment Modes
3.3
Alignment Modes
The MC92600 supports two types of alignment, byte alignment and word alignment. Byte
alignment deals with the MC92600 being congured as four separate receivers. Word
alignment deals with four receivers being congured to work together.
DDRE
Double data rate
enable
Indicates that the data interfaces are
running at double data rate (data is
output on the rising and falling edges of
clock.) Establishes DDR mode.
Input
High
BSYNC_0
Byte alignment mode
Denes the of word synchronization
event method. See Section 3.3.2.
Input
High
BSYNC_1
Byte alignment mode
Indicates the type of byte alignment to
employ in the receiver. See Section
Input
—
RCCE
Recovered clock enable
Indicates that the output data is
synchronized to its recovered byte
clock. Otherwise output data is
synchronized to the reference clock.
Input
High
ADIE
Add/delete idle enable
Indicates that the receiver is free to
add/delete idle characters to/from the
output data stream to maintain
alignment.
Input
High
REPE
Repeater mode enable
When enabled, the transmitter obtains
transmit data from the receiver.
Input
High
TST_0/
TST_1
Test mode
Indicates operating/test mode of the
chip. See Chapter 5.
Input
—
REF_CLK
Reference clock
System reference clock to which the
receiver interfaces may be timed.
Provided frequency is dependent on
HSE and DDRE settings.
Input
—
RLINK_x_N/
RLINK_x_P
Link serial receive data
Differential serial receive data input
pads.
Input
—
Internal Signals
rx_clock
High speed transceiver
clock
Internal, differential high speed clock
used to transmit and receive link data.
Input
—
loop_back_data
Loop back data
Differential loop back receive data.
Input
—
repeat_data
Received repeat data
Repeater mode, received data to
re-transmit.
Output
—
Table 3-1. MC92600 Receiver Interface Signals (continued)
Signal Name
Description
Function
Direction
Active
State
F
re
e
sc
a
le
S
e
m
ic
o
n
d
u
c
to
r,
I
Freescale Semiconductor, Inc.
