SLAS480B – JANUARY 2006 – REVISED DECEMBER 2008 ........................................................................................................................................... www.ti.com
Page 0 / Register 102:
Clock Generation Control Register (continued)
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D5-D4
R/W
00
PLLCLK_IN Source Selection
00: PLLCLK_IN uses MCLK
01: PLLCLK_IN uses GPIO2
10: PLLCLK _IN uses BCLK
11: Reserved. Do not use.
D3-D0
R/W
0010
PLL Clock Divider N Value
0000: N=16
0001: N=17
0010: N=2
0011: N=3
…
1111: N=15
Page 0 / Register 103–127:
Reserved Registers
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R
00000000
Reserved. Do not write to these registers.
Page 1 / Register 0:
Page Select Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D1
X
0000000
Reserved, write only zeros to these register bits
D0
R/W
0
Page Select Bit
Writing zero to this bit sets Page-0 as the active page for following register accesses. Writing a one to
this bit sets Page-1 as the active page for following register accesses. It is recommended that the user
read this register bit back after each write, to ensure that the proper page is being accessed for future
register read/writes. This register has the same functionality on page-0 and page-1.
Page 1 / Register 1:
Left Channel Audio Effects Filter N0 Coefficient MSB Register(1)
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
0x6B
Left Channel Audio Effects Filter N0 Coefficient MSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a 2’s
complement integer, with possible values ranging from –32768 to +32767.
(1)
Note that whenever any coefficient value is changed, the MSB register should be written first, immediately followed by theLSB register.
Even if only the MSB or LSB of the value changes, both registers should be written
Page 1 / Register 2:
Left Channel Audio Effects Filter N0 Coefficient LSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
0xE3
Left Channel Audio Effects Filter N0 Coefficient LSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a 2’s
complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 3:
Left Channel Audio Effects Filter N1 Coefficient MSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
0x96
Left Channel Audio Effects Filter N1 Coefficient MSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a 2’s
complement integer, with possible values ranging from –32768 to +32767.
76
Copyright 2006–2008, Texas Instruments Incorporated
Product Folder Link(s): TLV320AIC33
