1-27
Mitsubishi microcomputers
M30240 Group
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
Preliminary Specifications REV. E
Specifications in this manual are tentative and subject to change
Power Control
2.11.2 Division by 4 mode
The main clock is divided by 4 to obtain the internal clock
Φ
.
2.11.3 Division by 8 mode
The main clock is divided by 8 to obtain the internal clock
Φ
. Note that oscillation of the main clock
must have stabilized before transferring from this mode to another mode.
2.11.4 Division by 16 mode
The main clock is divided by 16 to obtain the internal clock
Φ
.
2.11.5 No-division mode
The main clock is used as internal clock.
Table 1.7:
Operating modes dictated by settings of system clock control registers 0 and 1
2.12 Power Control
The following is a description of the three available power control modes:
2.12.0.1 Normal Operation Mode
High-speed mode
Divide-by-1 frequency of the main clock become the internal clock
Φ
. The CPU operates with the internal clock
selected. Each peripheral function operates according to its assigned clock.
Medium-speed mode
Divide-by-2, divide-by-4, divide-by-8, or divide-by-16 frequency of the main clock becomes the internal clock
Φ
. The CPU operates according to the internal clock selected. Each peripheral function operates according
to its assigned clock.
2.12.0.2 Wait mode
The CPU operation is stopped. The oscillators do not stop.
2.12.0.3 Stop Mode
All oscillators stop. The CPU and all built-in peripheral functions stop. Of the three modes listed, this mode is
the most effective in decreasing power consumption.
CM17
CM16
CM06
Operating mode of internal clock
0
1
0
Division by 2 mode
1
0
0
Division by 4 mode
Invalid
Invalid
1
Division by 8 mode
1
1
0
Division by 16 mode
0
0
0
No-division mode
