Preliminary Data Sheet
PT7D6555
Extended PCM Interface Controller
42
PT0105(08/02)
Ver:0
Status Register (STAR) Address: 1AH(0/DH) Read
Value after reset: 00000101B
7 0
MAC
TAC
PSS
MFTO MFAB MFAE
MFRW MFFE
The status register STAR displays the current state of certain events within the PT7D6555. The STAR register bits do not
generate interrupts and are not modified by reading STAR.
MAC
Memory Access
0
…
no memory access is in operation.
1
…
a memory access is in operation. Hence, the memory access registers may not be used.
Note: MAC is also set and reset during synchronous transfers.
TAC
Timer Active
0
…
the timer is stopped.
1
…
the timer is running.
PSS
PCM Synchronization Status.
1
…
the PCM interface is synchronized.
0
…
the PCM interface is not synchronized. There is a mismatch between the PBNR value and the applied clock and
framing signals (PDC/PFS) or OMDR:OMS0 = 0.
MFTO
MF Channel Transfer in Operation.
0
…
no MF channel transfer is in operation.
1
…
an MF channel transfer is in operation.
MFAB
MF Channel Transfer Aborted.
0
…
the remote receiver did not abort a handshake message transfer.
1
…
the remote receiver aborted a handshake message transfer.
MFAE
MFFIFO Access Enable.
0
…
the MFFIFO may not be accessed.
1
…
the MFFIFO may be either read or written to.
MFRW
MFFIFO Read/Write.
0
…
the MFFIFO is ready to be written to.
1
…
the MFFIFO may be read.
MFFE
MFFIFO Empty
0
…
the MFFIFO is not empty.
1
…
the MFFIFO is empty.
