TC1765
Data Sheet
26
V1.2, 2002-12
Preliminary
Features of T0 and T1:
Each timer has a dedicated 32-bit reload register with automatic reload on overflow.
Timers can be split into individual 8-, 16-, or 24-bit timers with individual reload
registers.
Overflow signals can be selected to generate service requests, pin output signals, and
T2 trigger events.
Two input pins can define a count option.
Features of T2:
Count up or down is selectable
Operating modes:
–Timer
– Counter
– Quadrature counter (incremental/phase encoded counter interface)
Options:
– External start/stop, one-shot operation, timer clear on external event
– Count direction control through software or an external event
– Two 32-bit reload/capture registers
Reload modes:
– Reload on overflow or underflow
– Reload on external event: positive transition, negative transition, or both transitions
Capture modes:
– Capture on external event: positive transition, negative transition, or both
transitions
– Capture and clear timer on external event: positive transition, negative transition, or
both transitions
Can be split into two 16-bit counter/timers
Timer count, reload, capture, and trigger functions can be assigned to input pins. T0
and T1 overflow events can also be assigned to these functions.
Overflow and underflow signals can be used to trigger T0 and/or T1 and to toggle
output pins.
T2 events are freely assignable to the service request nodes.
