22
Agere Systems Inc.
Data Sheet
March 29, 2002
10 Gbits/s Clock Synthesizer, 16:1 Data Multiplexer
TTRN0110G
Frequency Characteristics
Reference Frequency (REFCLKP/N, REFFREQ) (Standard SONET Rate)
The device requires a 155.52 MHz or a 622.08 MHz differential LVDS reference clock input. Table 17 provides the
characteristics of the REFCLKP/N input.
Table 17. Reference Frequency Characteristics (Standard SONET)
Reference Frequency (REFCLKP/N, REFFREQ) (FEC Rate)
The device requires a (255/237)155.52 MHz or a (255/237)622.08 MHz differential LVDS reference clock input.
Table 18 provides the characteristics of the REFCLKP/N input.
Table 18. Reference Frequency Characteristics (FEC Rate)
Parameter
Min
Typ
Max
Unit
Reference Frequency (REFCLKP/N):
When REFFREQ = 0
When REFFREQ = 1
Duty Cycle
Phase Jitter
*
Temperature
Supply Voltage
—
—
40
—
0
3.15
155.52
622.08
50
—
25
—
—
—
60
MHz
MHz
%
ps(rms)
°C
V
* Measured under one 3.3 V LVDS load. Includes frequency components up to 8 MHz. Assumes
≤
0.500 ps for the device and
≤
0.100 ps
for laser driver and optics for a total rms jitter performance of less than 0.01 UI.
Specified range is to be compatible with environmental specification of TTRN0110G. Applications requiring a reduced temperature
range may specify the reference frequency oscillator accordingly.
0.750
85
3.45
Parameter
Min
Typ
Max
Unit
Reference Frequency (REFCLKP/N):
When REFFREQ = 0
When REFFREQ = 1
Duty Cycle
Phase Jitter
*
Temperature
Supply Voltage
—
—
40
—
0
3.15
(255/237)155.52
(255/237)622.08
50
—
—
—
—
—
60
MHz
MHz
%
ps(rms)
°C
V
* Measured under one 3.3 V LVDS load. Includes frequency components up to 8 MHz. Assumes
≤
0.500 ps for the device and
≤
0.100 ps
for laser driver and optics for a total rms jitter performance of less than 0.01 UI.
Specified range is to be compatible with environmental specification of TTRN0110G. Applications requiring a reduced temperature range
may specify the reference frequency oscillator accordingly.
0.750
85
3.45
