參數資料
型號： L80227
廠商： LSI CORP
元件分類： 網絡接口
英文描述： 10BASE-T/100BASE-TX Ethernet Physical Layer Device (PHY)(10BASE-T/100BASE-TX 以太網物理層處理器)
中文描述： DATACOM, ETHERNET TRANSCEIVER, PQFP64
封裝： LQFP-64
文件頁數： 53/158頁
文件大小： 1084K
代理商： L80227
Draft 6/5/00
Block Diagram Description
2-33
Copyright 1999 by LSI Logic Corporation. All rights reserved.
The default Normal Functions for PLED[5:0] are Receive Activity,
Transmit Activity, Link 100, Activity, Full Duplex, and Link 10, respectively.
Table 2.9
LED Event Definition
Symbol
Definition
RCV ACT
Receive activity occurred, stretch pulse to 100 ms
XMT ACT
Transmit activity occurred, stretch pulse to 100 ms
LINK
100 or 10 Mbits/s link detected
LINK+ACT
100 or 10 Mbits/s link detected or activity occurred, stretch
pulse to 100 ms (link detect causes LED to be on, activity
causes LED to blink)
ACT
Activity occurred, stretch pulse to 100 ms
LINK100
100 Mbit/s link detected
COL
Collision occurred, stretch pulse to 100 ms
FDX
Full-Duplex mode enabled
10/100
10 Mbits/s mode enabled (HIGH), or 100 Mbits/s mode
enabled (LOW)
LINK10
10 Mbits/s link detected
