Semiconductor
ML9050/9051
1/71
PEDL9050-02
132-Channel LCD Driver with Built-in RAM for LCD Dot Matrix Displays
GENERAL DESCRIPTION
The ML9050/9051 is an LSI for dot matrix graphic LCD devices carrying out bit map display.
This LSI can drive a dot matrix graphic LCD display panel under the control of an 8-bit
microcomputer. Since all the functions necessary for driving a bit map type LCD device are
incorporated in a single chip, using the ML9050/9051 makes it possible to realize a bit map type
dot matrix graphic LCD display system with only a few chips.
Since the bit map method in which one bit of display RAM data turns ON or OFF one dot in the
display panel, it is possible to carry out displays with a high degree of freedom such as Chinese
character displays, etc. With one chip, it is possible to construct a graphic display system with
a maximum of 132
￥
65 dots. The display can be expanded further using two chips.
The ML9050/9051 is made using a CMOS process. Because it has a built-in RAM, low power
consumption is one of its features, and is therefore suitable for displays in battery-operated
portable equipment.
The ML9050 has 65 common signal outputs and 132 segment signal outputs and one chip can
drive a display of up to 65
￥
132 dots.
The ML9051 has 49 common signal outputs and 132 segment signal outputs and one chip can
drive a display of up to 49
￥
132 dots.
This device is not resistant to radiation or to light.
FEATURES
Direct display of the RAM data using the bit map method
Display RAM data "1" ... Dot is displayed
Display RAM data "0" ... Dot is not displayed
Display RAM capacity
ML9050/9051: 65
￥
132 = 8580 dots
LCD Drive circuits
ML9050: 65 common outputs, 132 segment outputs
ML9051: 49 common outputs, 132 segment outputs
Microcomputer interface: Can select an 8-Bit parallel or serial interface
Built-in voltage multiplier circuit for the LCD drive power supply
Built-in LCD drive power supply adjustment circuit
Built-in LCD drive bias resistors
Line reversal drive/frame reversal drive (selected by a command)
Built-in oscillator circuit (Internal RC oscillator/external clock input)
A variety of commands
Read/write of display data, display ON/OFF, normal/reverse display, all dots ON/all dots
OFF, set page address, set display start address, etc.
Power supply voltage
Logic power supply: V
DD
-V
SS
= 1.8 V to 5.5 V
Voltage multiplier reference voltage: V
IN
-V
SS
= 1.8 V to V
DD
(5-Times multiplier
1.8 V to 3.6 V, 6-times multiplier
1.8 to 3 V, 7-times multiplier
1.8
to 2.5 V)
LCD Drive voltage: V
BI
-V
SS
= 6.0 to 18 V
Package: Gold bump chip, TCP
PEDL9050-02
This version: Dec. 1999
Previous version: Jun. 1999
