型號： ADSP-21160MKBZ-80
廠商： Analog Devices Inc
文件頁數： 6/52頁
文件大小： 0K
描述： IC DSP CONTROLLER 32BIT 400 BGA
產品培訓模塊： SHARC Processor Overview
標準包裝： 1
系列： SHARC®
類型： 浮點
接口： 主機接口，連接端口，串行端口
時鐘速率： 80MHz
非易失內存： 外部
芯片上RAM： 512kB
電壓 - 輸入/輸出： 3.30V
電壓 - 核心： 2.50V
工作溫度： 0°C ~ 85°C
安裝類型： 表面貼裝
封裝/外殼： 400-BBGA
供應商設備封裝： 400-PBGA（27x27）
包裝： 托盤
ADSP-21160M
–14–
REV. 0
ABSOLUTE MAXIMUM RATINGS
ESD SENSITIVITY
5 Applies to input pins with internal pull-ups: DR0, DR1.
6 Applies to input pins with internal pull-ups: DMARx, TMS, TDI, TRST.
7 Applies to three-statable pins: DATA63–0, ADDR31–0, PAGE, CLKOUT, ACK, FLAG3–0, REDY, HBG, BMS, BR6–1, TFSx, RFSx, TDO.
8 Applies to three-statable pins with internal pull-ups: DTx, TCLKx, RCLKx, EMU.
9 Applies to three-statable pins with internal pull-ups: MS3–0, RDx, WRx, DMAGx, PA, CIF.
10Applies to three-statable pins with internal pull-downs: LxDAT7–0, LxCLK, LxACK.
11Applies to ACK pulled up internally with 2 k
during reset or ID2–0= 00x.
12The test program used to measure I
DD-INPEAK represents worst case processor operation and is not sustainable under normal application conditions. Actual
internal power measurements made using typical applications are less than specified. For more information, see Power Dissipation on page 42.
13I
DDINHIGH is a composite average based on a range of high activity code. For more information, see Power Dissipation on page 42.
14I
DDINLOW is a composite average based on a range of low activity code. For more information, see Power Dissipation on page 42.
15Idle denotes ADSP-21160M state during execution of IDLE instruction. For more information, see Power Dissipation on page 42.
16Characterized, but not tested.
17Applies to all signal pins.
18Guaranteed, but not tested.
Internal (Core) Supply Voltage (V
DDINT)
1 . . .–0.3 V to +3.0 V
Analog (PLL) Supply Voltage (A
VDD)
. . . . .–0.3 V to +3.0 V
External (I/O) Supply Voltage (V
DDEXT) . . . .–0.3 V to +4.6 V
Input Voltage . . . . . . . . . . . . . . . . . . –0.5 V to V
DDEXT +0.5 V
Output Voltage Swing . . . . . . . . . . . –0.5 V to V
DDEXT +0.5 V
Load Capacitance . . . . . . . . . . . . . . . . . . . . . . . . . . 200 pF
Storage Temperature Range . . . . . . . . . . . –65C to +150C
Lead Temperature (5 seconds) . . . . . . . . . . . . . . . . . 185C
1 Stresses greater than those listed above may cause permanent damage to the device.
These are stress ratings only. Functional operation of the device at these or any
other conditions greater than those indicated in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for
extended periods may affect device reliability.
CAUTION:
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000V
readily accumulate on the human body and test equipment and can discharge without
detection. Although the ADSP-21160M features proprietary ESD protection
circuitry, permanent damage may occur on devices subjected to high-energy electro-
static discharges. Therefore, proper ESD precautions are recommended to avoid
performance degradation or loss of functionality.
