PI7C9X7954
PCI Express Quad UART
Datasheet
Page 38 of 70
May 2013 – Revision 1.4
Pericom Semiconductor
BIT
FUNCTION
TYPE
DESCRIPTION
3:0
Maximum Link
Speed
RO
Indicates the Maximum Link Speed of the given PCIe Link.
Defined encodings are: 0001b, which indicates 2.5 Gb/s Link
Reset to 1h.
9:4
Maximum Link
Width
RO
Indicates the maximum width of the given PCIe Link.
Reset to 000001b (x1).
11:10
Active State Power
Management
(ASPM) Support
RO
Indicates the level of ASPM supported on the given PCIe Link. The
I/O bridge supports L0s and L1 entry. The default value may be
changed by auto-loading from EEPROM.
Reset to 11b.
14:12
L0s Exit Latency
RO
Indicates the L0s exit latency for the given PCIe Link. The length of
time this I/O bridge requires to complete transition from L0s to L0 is
in the range of 256ns to less than 512ns. The default value may be
changed by auto-loading from EEPROM.
Reset to 011b.
17:15
L1 Exit
Latency
RO
Indicates the L1 exit latency for the given PCIe Link. The length of
time this I/O bridge requires to complete transition from L1 to L0 is
in the range of 16us to less than 32us. The default value may be
changed by auto-loading from EEPROM.
Reset to 000b.
23:18
Reserved
RO
Reset to 00000b.
31:24
Port Number
RO
It is not implemented. Hardwired to 00h.
6.2.54. LINK CONTROL REGISTER – OFFSET F0h
BIT
FUNCTION
TYPE
DESCRIPTION
1:0
Active State Power
Management
(ASPM) Control
RW
00b: ASPM is Disabled.
01b: L0s Entry Enabled.
10b: L1 Entry Enabled.
11b: L0s and L1 Entry Enabled.
Note that the receiver must be capable of entering L0s even when the
field is disabled.
Reset to 00b.
2
Reserved
RO
Reset to 0h.
3
Read Completion
Boundary (RCB)
RO
It is not implemented. Hardwired to 0b.
4
Link Disable
RO
It is not implemented. Hardwired to 0b.
5
Retrain Link
RO
It is not implemented. Hardwired to 0b.
6
Common Clock
Configuration
RW
0b: The components at both ends of a link are operating with
asynchronous reference clock.
1b: The components at both ends of a link are operating with a
distributed common reference clock.
Reset to 0b.
7
Extended Synch
RW
When set, it transmits 4096 FTS ordered sets in the L0s state for
entering L0 state and transmits 1024 TS1 ordered sets in the L1 state
for entering L0 state
Reset to 0b.
15:8
RsvdP
RO
Reset to 00h.
6.2.55. LINK STATUS REGISTER – OFFSET F0h
BIT
FUNCTION
TYPE
DESCRIPTION
13-0093
