- 您現在的位置：買賣IC網 > PDF目錄2121 > XRT83VSH316IB (Exar Corporation)IC LIU SH T1/E1/J1 16CH 316STBGA PDF資料下載
參數資料
| 型號： | XRT83VSH316IB |
| 廠商： | Exar Corporation |
| 文件頁數： | 81/98頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC LIU SH T1/E1/J1 16CH 316STBGA |
| 標準包裝： | 60 |
| 類型： | 線路接口裝置（LIU） |
| 驅動器/接收器數： | 16/16 |
| 規程： | T1，E1，J1 |
| 電源電壓： | 3.14 V ~ 3.47 V |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 316-LBGA |
| 供應商設備封裝： | 316-STBGA（21x21） |
| 包裝： | 托盤 |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁第60頁第61頁第62頁第63頁第64頁第65頁第66頁第67頁第68頁第69頁第70頁第71頁第72頁第73頁第74頁第75頁第76頁第77頁第78頁第79頁第80頁當前第81頁第82頁第83頁第84頁第85頁第86頁第87頁第88頁第89頁第90頁第91頁第92頁第93頁第94頁第95頁第96頁第97頁第98頁
XRT83VSH316
79
16-CHANNEL T1/E1/J1 SHORT-HAUL LINE INTERFACE UNIT
REV. 1.0.1
NOTE: The GIE bit in the global register 0x0000h must be set to "1" in addition to the individual register bits to enable the
interrupt pin.
TABLE 48: MICROPROCESSOR REGISTER 0XN05H BIT DESCRIPTION
CHANNEL N (0XN05H)
BIT
NAME
FUNCTION
Register
Type
Default
Value
(HW reset)
D7
Reserved
This Bit is Reserved
RO
0
D6
DMO
Digital Monitor Output
The digital monitor output is always active regardless if the inter-
rupt generation is disabled. This bit indicates the DMO activity. An
interrupt will not occur unless the DMOIE is set to "1" in the chan-
nel register 0xN04h and GIE is set to "1" in the global register
0x0000h.
0 = No Alarm
1 = Transmit output driver has failures
RO
0
D5
FLS
FIFO Limit Status
The FIFO limit status is always active regardless if the interrupt
generation is disabled. This bit indicates whether the RD/WR
pointers are within 3-Bits. An interrupt will not occur unless the
FLSIE is set to "1" in the channel register 0xN04h and GIE is set to
"1" in the global register 0x0000h.
0 = No Alarm
1 = RD/WR FIFO pointers are within ±3-Bits
RO
0
D4
LCV_OF
Line Code Violation / Counter Overflow
This bit serves a dual purpose. By default, this bit monitors the line
code violation activity. However, if bit 7 in register 0x0005h is set
to a "1", this bit monitors the overflow status of the internal LCV
counter. An interrupt will not occur unless the LCV_OFIE is set to
"1" in the channel register 0xN04h and GIE is set to "1" in the glo-
bal register 0x0000h.
0 = No Alarm
1 = A line code violation, bipolar violation, or excessive zeros has
occurred
RO
0
D3
Reserved
This Bit is Reserved
RO
0
D2
AISD
Alarm Indication Signal Detection
The alarm indication signal detection is always active regardless if
the interrupt generation is disabled. This bit indicates the AIS
activity. An interrupt will not occur unless the AISIE is set to "1" in
the channel register 0xN04h and GIE is set to "1" in the global reg-
ister 0x0000h.
0 = No Alarm
1 = An all ones signal is detected
RO
0
