DM9801A
1M Home Phoneline Network Physical Layer Single Chip Transceiver
Bit Name
Default
2.15-2.0
OUI_MSB
<0181H>
OUI Most Significant Bits:
This register stores bits 3 - 18 of the OUI (00606E) to bits 15 -
0 of this register respectively. The most significant two bits of
the OUI are ignored (the IEEE standard refers to these as bit 1
and 2)
26
Final
Version: DM9801A-DS-F01
May 30, 2001
Bit
Description
PHY Identifier Register #2 (PHYIDR2) - Register 3
Bit
Bit Name
3.15-3.10
OUI_LSB
Default
Description
<101110>,RO/P
OUI Least Significant Bits:
Bits 19 - 24 of the OUI (00606E) are mapped to bits 15 - 10 of
this register respectively
Vendor Model Number:
Six bits of the vendor model number mapped to bits 9 - 4 (most
significant bit to bit 9)
Model Revision Number:
Four bits of the vendor model revision number mapped to bits 3
- 0 (most significant bit to bit 3)
3.9-3.4
VNDR_MDL
<010000>,RO/P
3.3-3.0
MDL_REV
<0011>,RO/P
Auto-negotiation Advertisement Register(ANAR) - Register 4
This register contains the advertised abilities of the DM9801A device as they will be transmitted to link partners during Auto-
negotiation.
Bit
Bit Name
Default
4.15
NP
0,RO/P
Next Page Indication:
The DM9801A does not support the next page function. This bit
is permanently set to 0
4.14
ACK
0,RO/P
Acknowledge:
1=Link partner ability data reception acknowledged
0=Not acknowledged
The DM9801A's state machine will automatically control this
bit. Software should not attempt to write to this bit.
4.13
RF
0, RO/P
Remote Fault:
The DM9801A does not support this function. This bit is
permanently set to 0
4.12-4.11
Reserved
0, RO
Reserved:
Write as 0, ignore on read
4.10
FCS
0, RO/P
Flow Control Support:
The DM9801A does not support this function. This bit is
permanently set to 0
4.9
T4
0, RO/P
100Base-T4 Support:
The DM9801A does not support this function. This bit is
permanently set to 0
4.8
TX_FDX
0, RO/P
100Base-TX Full Duplex Support:
The DM9801A does not support this function. This bit is
permanently set to 0
4.7
TX_HDX
0, RO/P
100Base-TX Support:
The DM9801A does not support this function. This bit is
permanently set to 0
Description
