Intel
82801E C-ICH
Advance Information Datasheet
57
4.0
Electrical Characteristics
Note:
This document contains information on products in the sampling and initial production phases of
development. The specifications are subject to change without notice. Verify with your local Intel
sales office that you have the latest datasheet before finalizing a design.
4.1
Absolute Maximum Ratings
Note:
A non-condensing environment is required to maintain RTC accuracy.
Warning:
Stressing the device beyond the “Absolute Maximum Ratings” may cause permanent damage.
These are stress ratings only. See Section 4.2 for the Functional Operating Range of the 82801E
C-ICH.
4.2
Functional Operating Range
All of the AC and DC Characteristics specified in this document assume that the 82801E C-ICH
component is operating within the Functional Operating Range given in this section. Operation
outside of the Functional Operating Range is not recommended, and extended exposure outside of
the Functional Operating Range may affect component reliability.
Table 34. Absolute Maximum Ratings
Case Temperature under Bias
0o
C to +109o
C
Storage Temperature
-55o C to +150o C
Voltage on Any 3.3 V Pin with Respect to Ground
-0.5 to Vcc + 0.3 V
Voltage on Any 5 V Tolerant Pin with Respect to Ground
(V
REF
=5 V)
-0.5 to V
REF
+ 0.3 V
1.8 V Supply Voltage with Respect to Vss
-0.5 to +2.7V
3.3 V Supply Voltage with Respect to Vss
-0.5 to +4.6 V
5.0 V Supply Voltage (Vref) with Respect to Vss
-0.5 to +5.5 V
Maximum Power Dissipation
2.0 W
Table 35. Functional Operating Range
Case Temperature under Bias
0o C to +109o C
1.8 V Supply Voltage (VCC1_8) with respect to Vss
1.7 V to 1.9 V
3.3 V Supply Voltage (VCC3_3) with respect to Vss
3.102 V to 3.498 V
5 V Supply Voltage (V5REF) with respect to Vss
4.75 V to 5.25 V
