exit from Power Down mode saves the time for waiting crystal start-up. It is useful in the low
power system which usually be awakened from a short operation then returns to Power Down
mode.
6.6
Reset
The user has several hardware related options for placing the W925E/C240 into reset condition.
In general, most register bits go to their reset value irrespective of the reset condition, but there
are few flags that initial states are dependant on the source of reset. User can recognize the
cause of reset by reading the flags. There are three ways of putting the device into reset state.
They are External reset, Power on reset and Watchdog reset.
External Reset
The device continuously samples the RESET pin at state C4 of every machine cycle. Therefore,
the RESET pin must be held for at least 2 machine cycles to ensure detection of a valid RESET
low. The reset circuitry then synchronously applies the internal reset signal. Thus, the reset is a
synchronous operation and requires the clock to be running to cause an external reset.
Once the device is in reset condition, it will remain so as long as RESET is 0. Even after RESET
is deactivated, the device will continue to be in reset state for up to two machine cycles, and then
begin program execution from 0000h. There is no flag associated with the external reset
condition. However, since some flags indicate the cause of other two reset, the external reset can
be considered as the default reset if those two flags are cleared.
Watchdog Timer Reset
The Watchdog timer is a free running timer with programmable time-out intervals. The user can
reset the watchdog timer at any time to avoid producing the flag WDIF. If the Watchdog reset is
enabled and the flag WDIF is set high, the watchdog timer reset is performed after the additional
512 clocks come. This places the device into the reset condition. The reset condition is
maintained by hardware for two machine cycles. Once the reset is removed the device will begin
execution from 0000h.
6.7
Interrupt
The W925E/C240 has a two priority levels interrupt structure with 11 interrupt sources. Each of
the interrupt sources has an individual priority bit, flag, interrupt vector and enable bit. In addition,
the interrupts can be globally enabled or disabled.
Interrupt Sources
The External Interrupts INT0 and INT1 can be either edge triggered or level triggered,
depending on bits IT0 and IT1. The bits IE0 and IE1 in the TCON register are the flags which are
checked to generate the interrupt. In the edge triggered mode of the INT0 and the INT1 inputs
are sampled in every machine cycle. If the sample is high in one cycle and low in the next, then a
high to low transition is detected and the interrupts request flag IEx in TCON is set. The flag bit
requests the interrupt. Since the external interrupts are sampled every machine cycle, they have
to be held high or low for at least one complete machine cycle. The IEx flag is automatically
cleared when the service routine is called. If the level triggered mode is selected, then the
requesting source has to hold the pin low until the interrupt is serviced. The IEx flag will not be
cleared by the hardware on entering the service routine. If the interrupt continues to be held low
even after the service routine is completed, then the processor may acknowledge another
interrupt request from the same source. Note that the external interrupts INT2 to INT3 are edge
triggered only.
The TF0, TF1 flags generate the Timer 0, 1 Interrupts. These flags are set by the overflow in the
Timer 0, Timer 1. The TF0 and TF1 flags are automatically cleared by the hardware when the
timer interrupt is serviced.
