Real Time Clock (D31:F0)
The Real Time Clock (RTC) module provides a battery backed-up date and time keeping device
with two banks of static RAM with 128 bytes each, although the first bank has 114 bytes for
general purpose usage. Three interrupt features are available: time of day alarm with once a second
to once a month range, periodic rates of 122us to 500ms, and end of update cycle notification.
Seconds, minutes, hours, days, day of week, month, and year are counted. Daylight savings
compensation is optional. The hour is represented in twelve or twenty-four hour format, and data
can be represented in BCD or binary format. The design is meant to be functionally compatible
with the Motorola MS146818B. The time keeping comes from a 32.768 kHz oscillating source,
which is divided to achieve an update every second. The lower 14 bytes on the lower RAM block
has very specific functions. The first ten are for time and date information. The next four (0Ah to
0Dh) are registers, which configure and report RTC functions.
The time and calendar data should match the data mode (BCD or binary) and hour mode (12 or 24
hour) as selected in register B. It is up to the programmer to make sure that data stored in these
locations is within the reasonable values ranges and represents a possible date and time. The
exception to these ranges is to store a value of C0 - FF in the Alarm bytes to indicate a don’t care
situation. All Alarm conditions must match to trigger an Alarm Flag, which could trigger an Alarm
Interrupt if enabled. The SET bit of register B should be one while programming these locations to
avoid clashes with an update cycle. Access to time and date information is done through the RAM
locations. If a RAM read from the ten time and date bytes is attempted during an update cycle, the
value read does not necessarily represent the true contents of those locations. Any RAM writes
under the same conditions are ignored.
Note:
The ICH supports the ability to generate an SMI# based on Year 2000 rollover. See
Section 5.10.4
for more information on the century rollover.
The ICH does not implement month/year alarms.
5.10.1
Update Cycles
An update cycle occurs once a second, if the SET bit of register B is not asserted and the divide
chain is properly configured. During this procedure, the stored time and date are incremented,
overflow checked, a matching alarm condition checked, and the time and date rewritten to the
RAM locations. To maintain compatibility with the Motorola MS146818B, the update cycle starts
at least 244 us after the UIP bit of register A is asserted, and the entire cycle does not take more
than 1984 us to complete. The time and date RAM locations (0-9) will be disconnected from the
external bus during this time.
To avoid update and data corruption conditions, external RAM access to these locations can safely
occur at two times. When a updated-ended interrupt is detected, almost 999 ms is available to read
and write the valid time and date data. If the UIP bit of Register A is detected to be low, there is at
least 244 us before the update cycle begins.
Warning:
The overflow conditions for leap years and daylight savings adjustments are based on more than
one date or time item. To ensure proper operation when adjusting the time, the new time and data
values should be set at least two seconds before one of these conditions (leap year, daylight savings
time adjustments) occurs.
