T7630 Dual T1/E1 5.0 V Short-Haul Terminator (Terminator-II)
FDL Parameter/Control Registers (800—80E; E00—E0E)
(continued)
Table 195. FDL Transmitter Status Register (FDL_SR1) (80C; E0C)
* The count of FDL_SR1 bits 0—6 includes SF byte.
Table 196. FDL Receiver Status Register (FDL_SR2) (80D; E0D)
* Immediately following an FDL reset, the value in bit 0—bit 6 of this status register is 0. After the initial read of the FDL receive FIFO, the value
in bit 0—bit 6 of this status register is the number of bytes including SF byte that may be read from the FIFO.
Received FDL ANSIBit Codes Status Register (FDL_SR3)
The 6-bit code extracted from the ANSI code 111111110X
0
X
1
X
2
X
3
X
4
X
5
0 is stored in this register.
Table 197. Receive ANSIFDL Status Register (FDL_SR3) (80E; E0E)
Receive FDL FIFO Register (FDL_SR4)
This FIFO stores the received FDL data. Only valid FIFO bytes indicated in register FDL_SR2 may be read. Read-
ing nonvalid FIFO locations or reading the FIFO when it is empty will corrupt the FIFO pointer and will require an
FDL reset to restore proper FDL operation.
Table 198. FDL Receiver FIFO Register (FDL_SR4) (807; E07)
Bit
0—6
Symbol
FTQS0—
FTQS6
FTED
Description
FDL Transmit Queue Status.
Bit 0—bit 6 indicate how many bytes can be added to the
transmit FIFO*. The bits are encoded in binary where bit 0 is the least significant bit.
FDL Transmitter Empty Dynamic.
FTED = 1 indicates that the number of empty loca-
tions available in the transmit FIFO is greater than or equal to the value programmed in
the FTIL bits (FDL_PR3).
7
Bit
0—6
Symbol
FRQS0—
FRQS6
Description
FDL Receive Queue Status.
Bit 0—bit 6 indicate how many bytes are in the receive
FIFO, including the first status of Frame (SF) byte. The bits are encoded in binary where
bit 0 is the least significant bit*.
FDL End of Frame.
When
FEOF = 1, the receive queue status indicates the number of
bytes up to and including the first SF byte.
7
FEOF
B7
0
B6
0
B5
X5
B4
X4
B3
X3
B2
X2
B1
X1
B0
X0
Bit
0—7 FRD0—FRD7
FDL Receive Data.
The user data received via the FDL block are read through this register.
Symbol
Description
