IP100
BIT
14
IP100-DS-R03
May 27, 2003
29/92
Copyright
2003, IC Plus Corp.
All rights reserved.
Preliminary, Specification subject to change without notice.
BIT NAME
RxFrameError
BIT DESCRIPTION
Receive Frame Error. RxFrameError indicates that an error occurred during
receipt of the frame. The host system should examine RxFIFOOverrun,
RxRuntFrame, RxAlignmentError, RxFCSError, and RxOversizedFrame to
determine the type of error(s). RxFrameError is undefined until
RxDMAComplete is a logic 1.
Receive DMA Complete. RxDMAComplete indicates the frame transfer from
the IP100 to the host system is complete.
Receive FIFO Overrun. RxFIFOOverrun indicates the data was not removed
from the receive FIFO fast enough to keep up with the rate data was entering
the receive FIFO from the media. Bytes may be missing from the frame at one
or more unpredictable locations within the frame. RxFIFOOverrun is
undefined until RxDMAComplete is a logic 1.
Received Runt Frame. RxRuntFrame indicates the received frame was a runt
(less than 60 bytes in length, measured from the DA field to the end of the
Data field). RxRuntFrame is undefined until RxDMAComplete is a logic 1.
Receive Alignment Error. RxRuntFrame indicates that the received frame had
an alignment error. RxAlignmentError is undefined until RxDMAComplete is a
logic 1.
Receive Frame Check Sequence Error. RxFCSError indicates a FCS
checksum error on the frame data. RxFCSError is undefined until
RxDMAComplete is a logic 1
Receive Oversized Frame. RxOversizedFrame indicates the frame size was
equal to or greater than the value set in the MaxFrameSize register.
RxOversizedFrame is undefined until RxDMAComplete is a logic 1.
Reserved for future use.
Dribble Bits. DribbleBits indicates that the frame had accompanying dribble
bits. DribbleBits is informational only, and does not indicate a frame error.
Receive DMA Overflow. RxDMAOverflow indicates that the RFD did not have
sufficient buffer space to hold all of the frame data. For this condition, the
IP100 transfers as much data as possible and discards the remainder of the
frame.
Reserved for future use.
Implied Buffer Enable. ImpliedBufferEnable enables a special receive DMA
mode. If ImpliedBufferEnable is a logic 1 when the IP100 reads the RFD, the
IP100 will assume there is one receive buffer of length 1528 bytes, starting
immediately after ReceiveFrameStatus at (RFD address + 0x08).
The host system sets ImpliedBufferEnable when it prepares the RFD.
The IP100 tests ImpliedBufferEnable before receive DMA for a frame begins
at the same time it tests the RxDMAComplete bit. When the IP100 updates
RxFrameStatus field at the end of the receive DMA operation (in order to set
RxDMAComplete) the value written to ImpliedBufferEnable is undefined. The
host system cannot assume a certain value is left in ImpliedBufferEnable after
the RFD is used. Therefore, the host system must write the desired value to
ImpliedBufferEnable every time after releasing a RFD to the IP100.
Reserved for future use.
15
RxDMAComplete
16
RxFIFOOverrun
17
RxRuntFrame
18
RxAlignmentError
19
RxFCSError
20
RxOversizedFrame
22..21
23
Reserved
DribbleBits
24
RxDMAOverflow
27..25
28
Reserved
ImpliedBufferEnable
31..29
Reserved
