13.2 Diagnostic Circuit Operation
The T8110 internal diagnostic modes are intended primarily for chip manufacturing test. The diagnostic functions
include the following:
n
DIAG0—3, observability of internal test-points via FG(7:0), GP(7:0):
— Internal test-points are brought to chip I/O at FG and GP signals. Refer to Table 104 on page 129 and
Table 106 on page 131 for test-point assignment.
n
DIAG4—5, internal state counter diagnostic modes:
— Break counter carry chains—this is used in conjunction with monitoring of the state counter bits at FG and GP,
and breaks the 11-bit state counter into three separate pieces (bits [10:8], [7:4] and [3:0]).
— Shorten frame operation—the internally generated 8 kHz frame is bypassed in favor of the /FR_COMP input.
The /FR_COMP input still denotes the frame center and may be presented at a higher frequency than 8 kHz.
This is used in conjunction with the state counter modulo function, which when properly programmed allows
the internal state counter to roll over coincident with the /FR_COMP frame center.
n
DIAG6, microprocessor access to the virtual channel memory and minibridge register regions:
— The VC memory region is only functionally applicable for packet payload switching, which is only available
when the T8110 interface to a local PCI bus is selected. When interface to microprocessor bus is selected,
this diagnostic setting allows direct access to the virtual channel memory.
— The minibridge registers are only functionally applicable for minibridge port operation and are only available
when the T8110 interface to a local PCI bus is selected. When interface to microprocessor bus is selected,
this diagnostic setting allows direct access to the minibridge registers.
n
DIAG6, forced RESET of analog APLL1 feedback dividers:
— The APLL1 feedback dividers are typically not reset. This diagnostic mode allows each feedback divider to be
held in a reset state.
n
DIAG7, external buffer RETRY timer:
— The external buffer access protocol allows for one RETRY of a descriptor table fetch in the case of a locked
external buffer. This diagnostic register allows for manipulation of the amount of time to wait before retrying a
descriptor table fetch. Please see Section 14.2.3.4 on page 160 for more details.
n
DIAG8, interrupt controller diagnostics:
— When the diagnostic mode is enabled (DIAG8 register, bits 7:6 = 01), then bits 5:4 override the CLK error[1:0]
inputs, bits [3:2] override the SYS error[1:0] inputs, bit 1 overrides the GP[0] input, and bit 0 overrides the
FG[0] input to the interrupt controller. This allows for direct manipulation to set/clear a portion of interrupt bits
from each tier group. Please see Section 12.2 on page 125 for more details.
n
DIAG9, interrupt controller deassertion delay:
— Allows a programmable deassertion time for the SYSERR signal in between back-to-back interrupts.
n
DIAG10—11, sync-to-frame command delay:
— Allows a programmable delay time from the FRAME boundary for execution of the sync-to-frame clock com-
mands, GO_CLOCKS, CLEAR_FALLBACK, FORCE_FALLBACK.
